​This Practice provides requirements for use by a purchaser for determining the design criteria including design, materials of construction, inspection and testing for shell and plate heat exchangers constructed in accordance with ASME Boiler and Pressure Vessel Code, Section VIII, Division 1 or Division 2, henceforth referred to as the Code, and PIP VECV1001. Requirements that are specific to Code, Section VIII, Division 2 are shown in braces { }. This Practice provides requirements for purchasing shell and plate heat exchangers that are to be designed and fabricated by a manufacturer. This Practice also provides guidance for the development of purchase specifications for the construction of new shell and plate heat exchangers that meet the philosophy and requirements of Code, Section VIII, Division 1 {or 2} and PIP VECV1001.For some heat exchanger purchases, certain requirements in this Practice and in PIP VECV1001 may be assigned by the purchaser to the manufacturer. The specific requirements assigned (e.g., thermal design and the performance rating) can be specified on purchaser’s PIP VEDSP003 Data Sheet.​

This Practice provides data forms and the associated instructions for specifyingrequirements for shell and plate heat exchangers constructed in accordance with ASMEBoiler and Pressure Vessel Code, Section VIII, Division 1 or Division 2. Requirementsthat are specific to Code, Section VIII, Division 2 are shown in braces { }.This Practice contains four data forms for providing requirements for shell and plate heatexchangers having internal design pressures equal to or greater than 103 kPa (15 psig)and/or full vacuum external pressure at the top of the exchanger in its normal operatingposition, and are welded, shop- and field-fabricated, and in accordance with therequirements of the Code, Section VIII, Division 1 {or Division 2}.This Practice is required to be used with PIP VECV1001, PIP VESV1002,PIP VECSP001, and PIP VESSP002 to specify requirements that are required bymanufacturer to design and fabricate a shell and plate heat exchanger.​

​This Practice provides the detailed purchase descriptions for intermediate alloy steel globe valve tag numbers included in PIP Piping Material Specifications (PMSs) and used along with PIP PNSM0110 for the procurement of valves. This Practice also provides a cross reference for intermediate alloy steel globe valve tag numbers to applicable PIP PMSs.​

​This Practice provides detailed descriptions for the purchase of nickel and nickel alloy plug valves included in PIP Piping Material Specifications (PMSs).​

​This Practice provides the detailed purchase descriptions for carbon steel globe valve tag numbers included in PIP Piping Material Specifications (PMSs) and used along with PIP PNSM0110 for the procurement of valves. This Practice also provides a cross reference for carbon steel globe valve tag numbers to applicable PIP PMSs.​

​This Practice provides the detailed purchase descriptions for carbon steel check valve tag numbers included in PIP Piping Material Specifications (PMSs). This Practice also provides a cross reference for carbon steel check valve tag numbers to applicable PIP PMSs. Procurement of valves shall include the detailed purchase descriptions given in this Practice, along with the requirements in PIP PNSM0110 and the purchase order.​

​Practice provides the detailed purchase descriptions for stainless steel gate valve tag numbers included in PIP Piping Material Specifications (PMSs) and used along with PIP PNSM0110 for the procurement of valves. This Practice also provides a cross reference for stainless steel gate valve tag numbers to applicable PIP PMSs.​​

​This Practice provides fabrication and installation details for piping vents, drains, and instrumentation connections including:a. Hydrostatic Test Ventsb. Hydrostatic Test Drainsc. Valved Ventsd. Valved Drainse. Pressure Connectionsf. Thermowell Connectionsg. Orifice Flange Tap Connectionsh. Steam Drip StationsCross reference Table 1 Piping and Table 2 Pipeline are provided to relate the vent, drain, and instrument connection details to associated PIP Piping Material Specifications (PMSs) for Piping and Pipeline Systems. Cross reference Table 3 is provided to relate the steam drip station details to associated PIP Piping Material Specifications for steam service.​​

This Practice describes the minimum requirements for the structural design of process industry facilities at onshore sites.​ This Practice is intended to be used in conjunction with PIP ARC01015, PIP ARC01016, PIP CVC01015, PIP CVC01017, PIP CVC01018, and PIP STC01016, as applicable. This Practice does not include design criteria for loads associated with transportation or lifting of modular structures, which is addressed in PIP STC01016. This Practice provides triple references to ASCE/SEI 7-16, IBC 2018, and IBC 2021. The applicable code/standard shall be as required by the authority having jurisdiction (AHJ) and as specified in PIP CVC01017 and PIP CVC01018. This Practice provides double references to ACI 318-14 / ACI 318M-14 and ACI 318-19 (IN-LB) / ACI 318-19 (SI). The applicable code shall be as required by the authority having jurisdiction (AHJ) and as specified in PIP CVC01018. This Practice provides references to ANSI/AISC 341-16 and ANSI/AISC 360-16. The applicable specification/standard shall be as required by the authority having jurisdiction (AHJ) and as specified in PIP CVC01018. ​This Practice references US codes and standards, but it can be applied globally. For projects in other countries, a thorough search of applicable codes and standards is required. Where more stringent than US codes and standards, the local codes and standards shall govern. For projects in countries without applicable codes and standards, the US codes and standards shall govern.

​This Practice describes an engineering work process for gathering the necessary information and applying the applicable codes and standards to develop a documented area classification. This Practice addresses the classification of areas containing flammable liquids, gases, or vapors and combustible dust, but does not address ignitable fibers and flyings.This Practice applies to petroleum and chemical process facilities and other related industries that fall within the scope of the standards being used for the assessment of the area classification. This Practice is applicable for new and existing facilities.This Practice should be used with petroleum and chemical industry codes and standards that define the basis for area classification.​

​This Practice provides guidance for the use of PIP refractory Practices for the execution of a refractory lining project.​

​This Practice describes requirements for design, fabrication, inspection, and testing of metal-enclosed, cable bus assemblies for use on systems operating at 34.5 kV and below, and suitable for indoor and outdoor applications. ​

​This Practice provides requirements for the specification and installation of remotely actuated on-off valves. This Practice describes the requirements for process application, valve and actuator selection, material selection, ancillary equipment, and testing of remotely activated on-off valves (e.g., 2-way, 3-way, 4-way, etc.). This Practice covers non-throttling applications. Throttling applications are considered to be control valves and are covered in PIP PCCCV001 and PIP PCECV001. However, remotely activated on-off valves have many similarities with control valves (e.g., body configuration, materials of construction, internals, etc.). Therefore, this Practice shall be used in conjunction with PIP PCCCV001 and PIP PCECV001. This Practice does not cover process analytical sample valves.  ​

​This Practice provides requirements criteria for level measurement equipment selection and for the design of level measurement systems. This Practice describes the design requirements for differential pressure, radar, ultrasonic, displacement, capacitance, nuclear level measurement systems and switches for level gauges. This Practice does not include requirements for tank gauging systems or weighing systems. ​

T​his Practice provides the design requirements for temperature measurement equipment selection and for the design of temperature measurement systems. ​

​This Practice describes guidelines and background information for the application of remotely activated on-off valves. This Practice includes process application, valve and actuator selection, material selection, ancillary equipment requirements, and testing of remotely activated on-off valves (e.g., 2-way, 3-way, 4-way, etc.). This Practice covers non-throttling applications. Throttling applications are considered to be control valves and are covered in PIP PCECV001 and PIP PCCCV001. However, remotely activated on-off valves have many similarities with control valves (e.g., body configuration, materials of construction, internals, etc.). Therefore, this Practice should be used in conjunction with PIP PCECV001.​

​This Practice describes the minimum requirements for design, fabrication, inspection, testing, shipment, and documentation for high-temperature secondary batteries (salt batteries) for application in electrical stations, uninterruptible power supplies (UPS), battery energy storage (BES), or other applications located in indoor or outdoor, nonclassified areas. ​

​This practice defines the purpose and requirements of a Project Execution Plan (PEP) document. The practice provides key considerations to the development of the PEP document and standardized guidance to ensure consistency, clarity, and alignment in documenting how projects will be executed, monitored, and controlled throughout their lifecycle. The designation “Project,” as delineated within this document, encompasses a spectrum of work scopes that may be as small as engagement of a third-party entity for completing a small design study, or may be as large as executing complete engineering, procurement, and construction (EPC) activities for a greenfield facility. This practice has been developed considering a PEP for a large, greenfield EPC project, spanning early front-end loading (FEL) phases through commissioning.   This practice is not intended to provide the format, structure, or style for the development of the PEP but provides considerations to customize and use as project needs dictate.  ​​

​NA

​This Practice provides requirements for suppliers providing nickel and nickel alloy gate valves included in PIP Piping Material Specifications (PMSs). This Practice provides the detailed purchase descriptions for nickel and nickel alloy gate valve tag numbers included in PIP PMSs and used along with PIP PNSM0110 for the procurement of valves. This Practice also provides a cross reference for nickel and nickel alloy gate valve tag numbers to applicable PIP PMSs.
